3/4 in. 150 psi RJ Anti-Siphon Valve with Flow Control

Stock status: In stock
Country: United Kingdom
Description Specifications

Use this Lawn Genie 150 psi RJ Anti-Siphon Valve with Flow Control to help prevent irrigation water contaminants from entering the drinking water supply. This anti-siphon valve features a pressure-activated double-beaded diaphragm to strengthen the seal between the body and bonnet, external bleed, as well as flow control. The valve's low-voltage 24 VAC solenoid with captured plunger and a stainless-steel metering pin are built for durability and longevity.

  • Use in 24 VAC systems to help prevent irrigation water contaminants from entering the drinking water supply
  • Installed height should not be less than 6 in. above the highest downstream outlet
  • Self-aligning bonnet ensures correct installation
  • 5 - 25 GPM flow rate
  • Precise flow control adjustment reduces misting and fogging at the sprinkler to save water
  • Stainless-steel metering pin
  • 3/4 in. FNPT inlet and outlet
  • Captive solenoid plunger to help prevent lost parts during maintenance
  • Pressure-activated double-beaded diaphragm to strengthen the seal between the body and bonnet
  • External bleed to flush out dirt from the supply and lateral lines during new installations or repairs
  • 4-1/4 in. footprint size (center to center of inlet/outlet)
Inlet Size (in.) .75
Outlet Size (in.) 2 or less
Product Height (in.) 5.875
Product Length (in.) 5.125 in
Product Width (in.) 3.375 in
Compatible Pipe Material PVC
Connection Female Pipe Thread
Installation Above Ground
Irrigation System Component Valve
Material PVC
Maximum Pressure (psi) 150
Maximum Working Temperature (F) 120
Number of Outlets 1
Operation Automatic
Package Quantity 1
Pressure Rating 150 PSI
Product Weight (lb.) 1.185lb
Returnable 90-Day
Thread Type Female
Valve Type Anti-Siphone
Manufacturer Warranty 1 year
